• Power pack basic composition

  1) Pump  /  2) Oil tank

  3) Pressure, Temperature, Level Gauge

  4) Filter (Inlet / Outlet)

  5) Manifold (port)  /  6) Control Box

  7) Air-Breather  /  8) Sol valve  /  9) Relief valve







  · Flow late : 10 ~ 150 L/m

  · Maximum pressure : 700 bar

  · Power : AC220/3Φ, AC380/3Φ, AC440/3Φ





  This unit is used for the operation of ramp, door and hatch cover.
  It is also used for hydraulic line pressure test. As this system is small,
  lightweight and portable, it can be moved freely in the car deck.

Specification
